DN250 x 6m PN16 Cream Rhino Series 2 PVC-M Pipe Rieber RRJ
System PVC Pressure System
Product Code PDHRC16250
Product Properties
Size
250MM
Rating
PN16
Length
6.0M
Primary Material
PVC
UOM
LENGTHS
Rubber Ring Material
EPDM
Colour
Cream
Minimum Cover Depth
Not subject to vehicular loading 300mm |With vehicular loading, not in roadways 450mm | With vehicular loading, beneath sealed roadways 600mm |With vehicular loading, beneath unsealed roadways 750mm
Average Number of Joints per Litre-Iplex Lubricant
12
Allowable Operating Temperature - Degrees
50℃
Allowable Operating Pressure - 20 Degrees Celsius
1600kPa
Minimum Radius of Curvature
75m
Socket Deflection
1°
Maximum Diametric Deflection - 50yrs
7.50%
Unprotected UV Exposed
2 Years
Product Dimensions
Size
250MM
Inner Diameter
259.7mm
Weight
989kg
Crate Qty
8
Crate Weight
784kg
Wall Thickness
13.3mm
Socket Depth
205.3mm
Chamfer Detail
25mm
Witness Mark Detail
220mm
